Classic tone & dynamics control for the 5088.
The 5051 combines a three-band Inductor EQ based on Rupert’s vintage designs with the power & flexibility of the Portico II Compressor. Utilizing a fully-discrete class-A signal path and custom audio transformers and inductors, the 5051 delivers all the performance and musicality expected from a Rupert Neve design.

SPECIFICATIONS

LINE IN

FREQUENCY RESPONSE
Main Output, no load.
-3 dB @ 2.5 Hz
-3 dB @ 125 kHz

NOISE
Measured at Main Output, unweighted, 22 Hz - 22 kHz.
Terminated 40 Ohm, With gain at unity: better than -102 dBu
MAXIMUM INPUT
20 Hz to 20 kHz: +25 dBu
MAXIMUM OUTPUT
20 Hz to 20 kHz: +25 dBu
TOTAL HARMONIC DISTORTION AND NOISE
From <10 Hz to 80 kHz.
@ 1kHz, +20 dBu output: Better than 0.002%
@ 20Hz, +20 dBu out: Better than 0.120%
@ 20kHz, +20 dBu out: Better than 0.010%

EQUALIZER

NOISE
Measured at Main Output, unweighted, 22 Hz-22 kHz. Terminated 40 Ohm with all gains set at 0.
Better than -92 dBu
MAXIMUM INPUT
20 Hz to 20 kH: +24.5 dBu
MAXIMUM OUTPUT
20 Hz to 20 kHz: +24.5 dBu
TOTAL HARMONIC DISTORTION AND NOISE
From <10 Hz to 80 kHz.
@ 1kHz, +20 dBu output: Better than 0.007%
@ 20Hz, +20 dBu out: Better than 0.120%
@ 20kHz, +20 dBu out: Better than 0.070%

COMPRESSOR (Threshold at +20 dB, Ratio at 1.1:1, Gain at 0.)

NOISE
Measured at Main Output, unweighted, 22Hz - 22kHz. Terminated 40 Ohm.
Better than -92 dBu
MAXIMUM INPUT
20 Hz to 20 kHz: +25 dBu
MAXIMUM OUTPUT
20 Hz to 20 kHz: +25 dBu
TOTAL HARMONIC DISTORTION AND NOISE
From <10 Hz to 80 kHz.
@ 1 kHz, +20 dBu output: Better than 0.020%
@ 20 Hz, +20 dBu output: Better than 0.140%
@ 20 kHz, +20 dBu output: Better than 0.070%
THRESHOLD
Continuously Variable from -30 dBu to +20 dBu
RATIO
Continuously Variable from 1.1:1 to 40:1
GAIN
Continuously Variable from -6 dB to +20 dB
ATTACK
Continuously Variable from 20mS to 75mS
RELEASE
Continuously Variable from 100mS to 2.5 Seconds
UNIT DIMENSONS
9.375” H x 1.75” W
